Industrial Stainless Steel Inline Cartridge Filter Housing

SS304/316L inline cartridge filter housing for water treatment, food and beverage, pharmaceutical, chemical and industrial liquid filtration. Supports 10–40″ cartridges, sanitary tri-clamp ports and multiple filter media.

Consulta
Comparte tu aprecio
Categoría: Etiquetas: , ,

This stainless steel inline cartridge filter housing is constructed from SS304 or SS316L for single-cartridge liquid filtration. It accommodates 10″, 20″, 30″ and 40″ cartridges with DOE, 222 or 226 connections and can be configured with PP, PES, PTFE, Nylon or stainless steel filter media. Silicone, EPDM and FKM sealing options are available.

Designed for water treatment, food and beverage processing, pharmaceutical process filtration, chemical processing and general industrial liquid filtration, the housing supports filtration ratings from 0.1–200 μm depending on the installed cartridge. With flow rates up to 6 m³/h, operating pressure up to 10 bar and temperature up to 120°C, it provides flexible industrial filtration solutions for OEM equipment, filtration systems and industrial sourcing projects.

Industrial Stainless Steel Inline Cartridge Filter Housing (8)Industrial Stainless Steel Inline Cartridge Filter Housing (4)

Tipo

Sanitary Inline Cartridge Filter Housing
Material

SS304, SS316L
Longitud del cartucho

10", 20", 30", 40"
Índice de filtración

0.1–200 μm
Caudal

Up to 6 m³/h
Presión de funcionamiento

Max. 10 bar (145 psi)
Temperatura de funcionamiento

Max. 120°C
Conexión

1", 1.5", 2" Sanitary Tri-Clamp
Tratamiento de superficies

mirror polishing or electropolishing
